KV-AJA3.x-OEM TRI-BAND ANTENNA ARRAY

CATEGORY: Anti-Jamming Antennas

Home | Products | Anti-Jamming Solutions | Anti-Jamming Antennas | KV-AJA3.x-OEM

Application area

Characteristics

Tri-band multi constellation antenna array for Anti-Jamming GNSS systems and Jamming Suppression systems
Multi-frequency solution: L1 / L2 / L5/ S can be used (consider specified options)
4 receive channels for each frequency band
Easy to integrate, ideal for retrofitting

Application area

Characteristics

Tri-band multi constellation antenna array for Anti-Jamming GNSS systems and Jamming Suppression systems
Multi-frequency solution: L1 / L2 / L5/ S can be used (consider specified options)
4 receive channels for each frequency band
Easy to integrate, ideal for retrofitting

This is 4-elements Phased Array Antenna with frequency filtering at the antenna inputs and LNA onboard. The Anti-Jamming function is achieved by using it combined with Kosminis Vytis Anti-Jamming GNSS receiver or Jamming Suppressor which includes an Anti-Jamming GNSS processor. Signals acquired by Array Antenna are digitized and processed with KV-AJ3.x high dynamic range receivers or KV-4AJ4-RO high dynamic range Jamming Suppressors after which the navigation signals or solution is resistant to jammers.

A 4-element antenna array as part of the Anti-Jamming GNSS system or Jamming Suppression system allow gain pattern shapes to be changed in response to interference.
